Simplicity® Die Set Plain Linear Bearing of 2 inch ID (inner diameter.) Precision running clearance on the inner diameter of 0.0005” per side. Inch Series Precision ID Running Clearance Standard Size Linear and Rotational movement Self-Lubricating Bearing Liner: FrelonGOLD® is standard Optional liners include Frelon®J for corrosive chemical environments & FDA..
$148.26
Simplicity® Die Set Plain Linear Bearing of 1.5 inch ID (inner diameter.) Compensated running clearance on the inner diameter of 0.0015” per side. Inch Series Compensated ID Running Clearance Standard Size Linear and Rotational movement Self-Lubricating Bearing Liner: FrelonGOLD® is standard Optional liners include Frelon®J for corrosive chemical environments & FDA..
$107.29
Simplicity® Die Set Plain Linear Bearing of 3 inch ID (inner diameter). Compensated running clearance on the inner diameter of 0.0015” per side. Inch Series Compensated ID Running Clearance Standard Size Linear and Rotational movement Self-Lubricating Bearing Liner: FrelonGOLD® is standard Optional liners include Frelon®J for corrosive chemical environments & FDA..
$416.36
Simplicity® Die Set Plain Linear Bearing of 19mm ISO Metric ID (inner diameter.) Precision running clearance on the inner diameter of 0.0005” per side. ISO Metric Precision ID Running Clearance Standard Size Round Flange Linear and Rotational movement Self-Lubricating Bearing Liner: FrelonGOLD® is standard Optional liners include Frelon®J for corrosive chemical..
$66.61
Simplicity® Die Set Plain Linear Bearing of 2.5 inch ID (inner diameter.) Precision running clearance on the inner diameter of 0.0005” per side. Inch Series Precision ID Running Clearance Standard Size Linear and Rotational movement Self-Lubricating Bearing Liner: FrelonGOLD® is standard Optional liners include Frelon®J for corrosive chemical environments & FDA..
$286.27
Simplicity® Die Set Plain Linear Bearing of 40mm ISO Metric ID (inner diameter.) Precision running clearance on the inner diameter of 0.0005” per side. ISO Metric Precision ID Running Clearance Standard Size Round Flange Linear and Rotational movement Self-Lubricating Bearing Liner: FrelonGOLD® is standard Optional liners include Frelon®J for corrosive chemical..
$123.76
Simplicity® Die Set Plain Linear Bearing of 1.25 inch ID (inner diameter.) Precision running clearance on the inner diameter of 0.0005” per side. Inch Series Precision ID Running Clearance Standard Size Linear and Rotational movement Self-Lubricating Bearing Liner: FrelonGOLD® is standard Optional liners include Frelon®J for corrosive chemical environments & FDA..
$95.01
Simplicity® Die Set Plain Linear Bearing of 80mm ISO Metric ID (inner diameter.) Precision running clearance on the inner diameter of 0.0005” per side. ISO Metric Precision ID Running Clearance Standard Size Round Flange Linear and Rotational movement Self-Lubricating Bearing Liner: FrelonGOLD® is standard Optional liners include Frelon®J for corrosive chemical..
$434.55
Simplicity® Die Set Plain Linear Bearing of 63mm ISO Metric ID (inner diameter.) Precision running clearance on the inner diameter of 0.0005” per side. ISO Metric Precision ID Running Clearance Standard Size Round Flange Linear and Rotational movement Self-Lubricating Bearing Liner: FrelonGOLD® is standard Optional liners include Frelon®J for corrosive chemical..
$295.56
Simplicity® Die Set Plain Linear Bearing of 50mm ISO Metric ID (inner diameter.) Precision running clearance on the inner diameter of 0.0005” per side. ISO Metric Precision ID Running Clearance Standard Size Round Flange Linear and Rotational movement Self-Lubricating Bearing Liner: FrelonGOLD® is standard Optional liners include Frelon®J for corrosive chemical..
$156.56
Simplicity® Die Set Plain Linear Bearing of 25mm ISO Metric ID (inner diameter.) Precision running clearance on the inner diameter of 0.0005” per side. ISO Metric Precision ID Running Clearance Standard Size Linear and Rotational movement Self-Lubricating Bearing Liner: FrelonGOLD® is standard Optional liners include Frelon®J for corrosive chemical environments &..
$79.93
Simplicity® Die Set Plain Linear Bearing of 32mm ISO Metric ID (inner diameter.) Precision running clearance on the inner diameter of 0.0005” per side. ISO Metric Precision ID Running Clearance Standard Size Round Flange Linear and Rotational movement Self-Lubricating Bearing Liner: FrelonGOLD® is standard Optional liners include Frelon®J for corrosive chemical..
$99.96
Double Die Set Plain Linear Bearing of 1.25 inch ID (inner diameter.) The compensated running clearance of 0.0015" per side provides more clearance between the inner diameter and shaft allowing the bearing to perform like a linear ball bearing. Inch Series Compensated ID Running Clearance Double Size Round Center Flange..
$261.51
Compensated ID Round Flanged (End Mount) Double Plain Linear Bearing with a 25mm ISO Metric ID (inner diameter). The compensated running clearance on the inner diameter is 0.0015” for those who prefer speed over precision. Self-Lubricating Bearing Liner: FrelonGOLD® is standard; Optional liners include Frelon® W (FDA compliant) & Frelon® J..
$115.56
Compensated ID Round Flanged (End Mount) Double Plain Linear Bearing with a 30mm ISO Metric ID (inner diameter). The compensated running clearance on the inner diameter is 0.0015” for those who prefer speed over precision. Self-Lubricating Bearing Liner: FrelonGOLD® is standard; Optional liners include Frelon® W (FDA compliant) & Frelon® J..
$171.77
Round Flanged (End Mount) Double Plain Linear Bearing with a 50mm ISO Metric ID (inner diameter) and a precision running clearance on the inner diameter of 0.0005” for those who prefer precision over speed. Self-Lubricating Bearing Liner: FrelonGOLD® is standard; Optional liners include Frelon® W (FDA compliant) & Frelon® J ISO..
$423.18
Compensated ID Round Flanged (End Mount) Double Plain Linear Bearing with a 60mm ISO Metric ID (inner diameter). The compensated running clearance on the inner diameter is 0.0015” for those who prefer speed over precision. Self-Lubricating Bearing Liner: FrelonGOLD® is standard; Optional liners include Frelon® W (FDA compliant) & Frelon® J..
$627.28
Round Flanged (End Mount) Double Plain Linear Bearing with a 60mm ISO Metric ID (inner diameter) and a precision running clearance on the inner diameter of 0.0005” for those who prefer precision over speed. Self-Lubricating Bearing Liner: FrelonGOLD® is standard; Optional liners include Frelon® W (FDA compliant) & Frelon® J ISO..
$627.28
Round Flanged (End Mount) Double Plain Linear Bearing with a 40mm ISO Metric ID (inner diameter) and a precision running clearance on the inner diameter of 0.0005” for those who prefer precision over speed. Self-Lubricating Bearing Liner: FrelonGOLD® is standard; Optional liners include Frelon® W (FDA compliant) & Frelon® J ISO..
$294.84
Compensated ID Round Flanged (End Mount) Double Plain Linear Bearing with a 50mm ISO Metric ID (inner diameter). The compensated running clearance on the inner diameter is 0.0015” for those who prefer speed over precision. Self-Lubricating Bearing Liner: FrelonGOLD® is standard; Optional liners include Frelon® W (FDA compliant) & Frelon® J..
$423.18
Plain Linear Bearings from PBC Linear®, featuring the self-lubricating FrelonGOLD® PTFE-based liner, which minimizes friction and wear, eliminates external lubrication needs, and outperforms in harsh, hot, or dirty environments. Available as stand-alone regular linear bearings with straight or crowned anodized aluminum shells (open or closed), as straight or flanged sleeve bearings, inside standard-sized or double-sized pillow blocks (open or closed), or as standard or double-sized flanged variants. Optional Frelon® J liners provide resistance to corrosive chemicals, while Frelon® W liners ensure FDA compliance. These bearings support rotary, linear, or oscillating motion, with precision or compensated running clearances. Offered in Inch, ISO Metric, or JIS Metric ID series, they deliver maintenance-free performance across a wide temperature range. The 2:1 binding rule applies.
- Sizing Options: Inch, metric, and JIS sizes available
- Available in open, closed and thin-wall styles
- ID Sizes: Available from 3/16” to 4” Inch Series, 5mm to 80mm Metric Series
- Shaft Lengths: Up to 12 feet
- Shell Material: Standard is aluminum; stainless steel shells are available
- Maximum Speed: Up to 8 m/s (315 in/s)
- Temperature Rating: -400°F to +400°F or -240°C to 204°C
- Maximum Horizontal Static Load: 2,165 to 100,500 lb (982 to 45,586 kg)
- Seal Options: Nitrile rubber, urethane, and viton seals available from ½” ID and up or 20mm and up
- Mounting Options: O-ring and retaining ring grooves for multiple mounting options
- External Lubrication: Optional feature for added lubrication
- Vibration Damping: Ensures smooth and quiet operation
View our full Plain Linear Bearing Product Features page
