Linear Ball Bearing Pillow Blocks - Closed Single
Ways to Order
Linear ball bearing pillow block, closed-shelled, with a 1.5" ID standard-size linear ball bearing mounted inside an aluminum alloy housing. The closed design is intended for end-supported round shafts. A heat-treated alloy steel bearing shell, recirculating hardened steel balls, and a resin retainer provide durable, low-friction motion with reduced operating..
$193.28
Linear ball bearing pillow block with a 25mm standard-size, closed-shelled bearing mounted inside an aluminum alloy housing. Designed for end-supported round shafts, the bearing uses a heat-treated alloy steel shell, recirculating hardened steel balls, and a resin retainer for durable, low-friction motion with reduced operating noise. Linear ball bearings are..
$98.48
Linear ball bearing pillow block with a 10mm standard-size, closed-shelled bearing mounted inside an aluminum alloy housing. Designed for end-supported round shafts, the bearing uses a heat-treated alloy steel shell, recirculating hardened steel balls, and a resin retainer for durable, low-friction motion with reduced operating noise. Linear ball bearings are..
$53.59
Linear Ball Bearing Pillow Block, closed, with a 1" ID (inner diameter), featuring a linear ball bearing inside an aluminum alloy housing, incorporating a heat-treated alloy steel shell for enhanced durability, a resin retainer polymer cage for reduced noise, and double seals at no extra cost for contaminant protection. Size-interchangeable..
$103.08
Linear ball bearing pillow block, closed-shelled, with a 3/8" ID standard-size linear ball bearing mounted inside an aluminum alloy housing. The closed design is intended for end-supported round shafts. A heat-treated alloy steel bearing shell, recirculating hardened steel balls, and a resin retainer provide durable, low-friction motion with reduced operating..
$55.63
Linear ball bearing pillow block with a 1.5" standard-size, closed-shelled Precision Plus® self-aligning bearing mounted inside an aluminum alloy housing. The self-aligning design uses floating internal raceway elements that can shift slightly to accommodate minor shaft and housing misalignment while maintaining smooth rolling contact. The closed-shell design is intended for..
$260.22
Linear ball bearing pillow block with a 50mm standard-size, closed-shelled bearing mounted inside an aluminum alloy housing. Designed for end-supported round shafts, the bearing uses a heat-treated alloy steel shell, recirculating hardened steel balls, and a resin retainer for durable, low-friction motion with reduced operating noise. Linear ball bearings are..
$279.76
Linear ball bearing pillow block with a 40mm standard-size, closed-shelled bearing mounted inside an aluminum alloy housing. Designed for end-supported round shafts, the bearing uses a heat-treated alloy steel shell, recirculating hardened steel balls, and a resin retainer for durable, low-friction motion with reduced operating noise. Linear ball bearings are..
$185.30
Linear ball bearing pillow block with a 16mm standard-size, closed-shelled bearing mounted inside an aluminum alloy housing. Designed for end-supported round shafts, the bearing uses a heat-treated alloy steel shell, recirculating hardened steel balls, and a resin retainer for durable, low-friction motion with reduced operating noise. Linear ball bearings are..
$64.58
Linear ball bearing pillow block with a 20mm standard-size, closed-shelled bearing mounted inside an aluminum alloy housing. Designed for end-supported round shafts, the bearing uses a heat-treated alloy steel shell, recirculating hardened steel balls, and a resin retainer for durable, low-friction motion with reduced operating noise. Linear ball bearings are..
$69.28
Linear ball bearing pillow block with a 30mm standard-size, closed-shelled bearing mounted inside an aluminum alloy housing. Designed for end-supported round shafts, the bearing uses a heat-treated alloy steel shell, recirculating hardened steel balls, and a resin retainer for durable, low-friction motion with reduced operating noise. Linear ball bearings are..
$145.80
Linear ball bearing pillow block with a 12mm standard-size, closed-shelled bearing mounted inside an aluminum alloy housing. Designed for end-supported round shafts, the bearing uses a heat-treated alloy steel shell, recirculating hardened steel balls, and a resin retainer for durable, low-friction motion with reduced operating noise. Linear ball bearings are..
$58.63
Linear ball bearing pillow block, closed-shelled, with a 3/4" ID standard-size linear ball bearing mounted inside an aluminum alloy housing. The closed design is intended for end-supported round shafts. A heat-treated alloy steel bearing shell, recirculating hardened steel balls, and a resin retainer provide durable, low-friction motion with reduced operating..
$72.33
Linear ball bearing pillow block with an 8mm standard-size, closed-shelled bearing mounted inside an aluminum alloy housing. Designed for end-supported round shafts, the bearing uses a heat-treated alloy steel shell, recirculating hardened steel balls, and a resin retainer for durable, low-friction motion with reduced operating noise. Linear ball bearings are..
$51.31
Linear ball bearing pillow block, closed-shelled, with a 1/2" ID standard-size linear ball bearing mounted inside an aluminum alloy housing. The closed design is intended for end-supported round shafts. A heat-treated alloy steel bearing shell, recirculating hardened steel balls, and a resin retainer provide durable, low-friction motion with reduced operating..
$61.22
Linear ball bearing pillow block, closed-shelled, with a 1/4" ID standard-size linear ball bearing mounted inside an aluminum alloy housing. The closed design is intended for end-supported round shafts. A heat-treated alloy steel bearing shell, recirculating hardened steel balls, and a resin retainer provide durable, low-friction motion with reduced operating..
$53.86
Linear ball bearing pillow block, closed-shelled, with a 5/8" ID standard-size linear ball bearing mounted inside an aluminum alloy housing. The closed design is intended for end-supported round shafts. A heat-treated alloy steel bearing shell, recirculating hardened steel balls, and a resin retainer provide durable, low-friction motion with reduced operating..
$67.85
Linear ball bearing pillow block with a 1.25" standard-size, closed-shelled Precision Plus® self-aligning bearing mounted inside an aluminum alloy housing. The self-aligning design uses floating internal raceway elements that can shift slightly to accommodate minor shaft and housing misalignment while maintaining smooth rolling contact. The closed-shell design is intended for..
$206.38
Linear ball bearing pillow block with a 1" standard-size, closed-shelled Precision Plus® self-aligning bearing mounted inside an aluminum alloy housing. The self-aligning design uses floating internal raceway elements that can shift slightly to accommodate minor shaft and housing misalignment while maintaining smooth rolling contact. The closed-shell design is intended for..
$140.42
Linear ball bearing pillow block with a 3/4" standard-size, closed-shelled Precision Plus® self-aligning bearing mounted inside an aluminum alloy housing. The self-aligning design uses floating internal raceway elements that can shift slightly to accommodate minor shaft and housing misalignment while maintaining smooth rolling contact. The closed-shell design is intended for..
$97.70
Closed-shell, single-size linear ball bearing pillow blocks use an inserted standard-size bearing inside a rigid aluminum alloy housing to provide compact, high-speed linear motion, especially in cantilevered, overhung, and offset-load applications where they avoid the same 2:1 binding limitation that applies to plain bearings. Heat-treated alloy steel bearing shells, recirculating steel balls, and polymer resin retainers support smooth operation with a low coefficient of friction and reduced operating noise, while double seals help retain lubricant and protect against contaminants. PBC Linear® offers these pillow blocks in inch sizes from 0.25" to 2" and metric sizes from 8mm to 50mm, with static load capacities up to 1,700lb (7,900N) and dynamic load capacities up to 850lb (3,800N). Sizes are interchangeable with industry-standard dimensions and corresponding Simplicity® plain bearings. Precision Plus® self-aligning versions are also available, using floating internal ball raceways to accommodate minor shaft and housing misalignment. Operating temperature ranges from -4°F to 176°F (-20°C to 80°C).
- Standard-size closed linear ball bearings for end-supported round shafts
- ID sizes: 0.25" to 2" and 8mm to 50mm
- Static load capacities up to 1,700lb (7,900N)
- Dynamic load capacities up to 850lb (3,800N)
- Low coefficient of friction for smooth, high-speed linear motion
- Heat-treated alloy steel shell for durability
- Recirculating hardened steel balls for efficient rolling motion
- Resin retainer helps reduce operating noise
- Double seals standard for lubricant retention and contaminant protection
- Requires external lubrication for proper bearing performance and service life
- Recommended lubrication: ISO VG 32–68 turbine oil or No. 2 lithium soap grease
- Lubricate the bearing and shaft before first use
- Re-lubricate periodically based on load, speed, stroke, temperature, and contamination
- Temperature range: -4°F to 176°F (-20°C to 80°C)
- Well suited to cantilevered, overhung, and offset-load applications
- Handles off-center forces without the same 2:1 binding limit as plain bearings
- Interchangeable with industry-standard sizes and Simplicity® plain bearings
- Precision Plus® self-aligning versions also available
