Low Profile Linear Guide Carriage - Redi-Rail RRL34C-A2-019A-C0 Width: 90mm, 4 Hardened Steel Rollers
Low-profile linear guide carriage with four sealed hardened steel gothic-arch cam rollers for the Redi-Rail RRL34R rail. The carriage is 76.2mm wide × 90mm long, with an ultra-low assembled rail-and-carriage height of just 19mm, making it ideal for height-constrained machinery and automation applications. Its sealed, double-row gothic-arch cam rollers travel along the rail's hardened steel shaft raceways for smooth, quiet, low-friction linear motion. The clear-anodized aluminum carriage features a flat mounting plate and side-adjustable preload for precise movement and positioning of loads. Hardened steel rollers and raceways provide durability and wear resistance, while sealed bearings help protect against contamination in demanding operating environments.
- Carriage only; compatible Redi-Rail RRL34R rail sold separately
- Carriage width: 76.2mm | Length: 90mm
- Ultra-low assembled rail-and-carriage height: 19mm
- Four sealed, double-row hardened steel gothic-arch cam rollers
- Compatible with RRL34R rails featuring hardened steel shaft raceways
- Clear-anodized aluminum carriage body for corrosion resistance
- Side-adjustable preload for precise carriage alignment and reduced play
- Sealed roller bearings help protect against dust and contaminants
- Load capacity up to 489 N (110 lb)
- Flat-plate carriage design for convenient load mounting
- Optional oil-impregnated wiper seals for continuous raceway lubrication
- Ideal for compact automation, medical devices, and tight spaces
