Belt Driven Linear Actuator UGT040D-B21-0200-BD1ZG-00L0-0 - V-Rail Length: 200mm w/ NEMA 23 Motor Mount

Belt-driven linear actuator with a NEMA 23 motor mount and a pair of parallel 200mm-long v-rails for moving and accurately positioning loads. The actuator features a v-wheel carriage on a 40mm-tall and 40mm-wide aluminum rail profile. The motor mount accommodates a compatible, programmable NEMA 23 stepper motor, sold separately. Once motorized, the belt drives the carriage, whose sealed stainless steel v-wheels roll along the parallel v-rails to provide smooth, stable linear motion. The tall-profile rail assembly provides structural rigidity and maintains carriage alignment during travel. PBC Linear's SIMO® manufacturing process machines aluminum extrusions with synchronized cutters in a single pass, achieving twice the flatness and dimensional tolerances of 0.050mm.

• Belt-driven linear actuator with NEMA 23 motor mount
• Pair of parallel V-rails of length: 200mm
• Linear V-rail height: 40mm
• Linear V-rail width: 40mm
• Motor sold separately
• Belt drive converts motor rotation into linear carriage movement
• Sealed stainless steel V-wheels roll along angled rail surfaces
• Tall-profile aluminum rail provides structural rigidity
• Rolling-element carriage guidance for smooth, controlled motion
• SIMO® machining process provides 2× better rail flatness
• Precision-machined aluminum rail with 0.050mm tolerances
• Single-pass synchronized machining improves rail alignment
• Applications: Industrial automation, material handling and equipment positioning
