Low Profile Linear Carriage - Mini-Rail LPM27C Carriage for Rail Width: 27mm

Low Profile Mini-Rail Linear Carriage LPM27C, a 13.5mm molded polymer slider carriage with stainless steel threaded inserts for use with LPM27 series rails. High load capacity with ≤0.5mm running clearance.

  • Compatible rails: LPM27R-0100, LPM27R-0150, LPM27R-0400, LPM27R-0750, LPM27R-1000
  • Carriage length: 13.5mm | For rail width: 27mm
  • Molded polymer with stainless steel threaded inserts
  • Resistant to contaminants, dyes, and weak acids
  • Standard sizing compatible with other linear guides
  • ≤0.5 mm running clearance
  • Carriage only — rail sold separately

PDF View Catalog

3D Models

TypeFileFormatLink
3dLPM27C.x_tSolidWorks >=2006View
cadLPM27C.stepSTEP AP214Download
$6.34
Configure Custom Length

Max Length: 3,600 mm

Ask about this product
Chat Now
Dimensions
Videos
Resources

Product Dimensions

Approx. Weightwidthlengthheight
0.0106 lbs1.063 in0.5315 in0.374 in
