Low Profile Linear Carriage - Mini-Rail LPM17C Carriage for Rail Width: 17mm

Low Profile Mini-Rail Linear Carriage LPM17C, a 8.5mm molded polymer slider carriage with stainless steel threaded inserts for use with LPM17 series rails. High load capacity with ≤0.5mm running clearance.

  • Compatible rails: LPM17R-0100, LPM17R-0125, LPM17R-0150, LPM17R-0200, LPM17R-0250
  • Carriage length: 8.5mm | For rail width: 17mm
  • Molded polymer with stainless steel threaded inserts
  • Resistant to contaminants, dyes, and weak acids
  • Standard sizing compatible with other linear guides
  • ≤0.5 mm running clearance
  • Carriage only — rail sold separately

PDF View Catalog

3D Models

TypeFileFormatLink
3dLPM17C.x_tSolidWorks >=2006View
cadLPM17C.stepSTEP AP214Download
$3.81
Configure Custom Length

Max Length: 3,600 mm

Ask about this product
Chat Now
Dimensions
Videos
Resources

Product Dimensions

Approx. Weightwidthlengthheight
0.0024 lbs0.6693 in0.3346 in0.2362 in
