Lead Screw Assembly LSR1605T-0508-RS-NNN-NNN-N Round Nut
Lead screw with a standard round nut, 508mm length, 16mm diameter, 5mm lead, and made of precision-rolled 300 Series stainless steel coated with PTFE to reduce friction and prevent flaking. With an exceptional lead accuracy of 0.003"/ft (76 µm/300 mm), the lead screw exceeds industry standards, providing improved straightness, a smoother finish, and greater durability. The standard round nut (RS) provides a compact cylindrical profile for general linear motion applications, with an anti-backlash version (RCF) available to reduce play and improve positioning stability.
- Length: 508mm
- Screw Diameter: 16mm
- Lead: 5mm
- Nut Type: Standard Round Nut
- Motor: No Motor
- Coating: PTFE (over stainless steel)
- Thread Direction: Right Hand - Clockwise
- Lead Accuracy: 0.003"/ft (76 µm/300 mm)
ASY LD SCR NUT LS 16x5x2 0508mm RS
